X348 Trolley | 3" I-Beam Overhead Conveyor Trolley

CamelConvey trolleys are offered in 2 inch, 3 inch, 4 inch and 6 inch sizeswith a variety of potions. These overhead trolleys are available in either full ball complement or retainer configurations. The full ball complement trolley wheel contains the maximum number of precison ball bearings and is designed for heavy duty or high heat applications. The retainer type trolley wheel has each precsion ball bearing separted and equally spaced around the perophery of the bearing race by a two piece steel retainer cage. The retainer type wheel is designed primarily for transportaiton and parts delivery systems. It is generally not suited for heavy duty or high heat applications. 3'' overhead trolley with a 5 1/2" drop has a load capacity of 200 pounds per single trolley. 400 pound capacity with load bar.

3" I-Beam Overhead Conveyor Trolley assembly consists of two half trolleys with full ball bearing complement type wheels and a standard "I" attachment. Does NOT included center chain link - for reference only.

Sometimes the drop distance is measured from the top of the conveyor I-beam and in other cases the drop distance is measured from the bottom of the I-beam.

3" I beam trolley assembly consists of two half trolleys with full ball bearing complement type wheels, a standard "I" or "H" or "B" attachment and necessary sets of bolts and nuts as shown in the photograph on this page.

Related products

The overhead conveyor components including drop forged rivetless chain, drop forged overhead trolley, drive chain, trolley attachment, side link pusher dog, rollers turn roller, enclosed track chain, free carrier trolley and so on.

FAQ

What's Your Packing Method?

For our regular products like X348, X458, X678 forged rivetless chain, trolley, attachment packed into plywood case which no need fumigate, for the assembled conveyor chain and forged fork chain with flight packed into pallet,for CC600 casting chain two packing methods are available.
